Tumaker NX Pro Pellets

3D Pellets Printer

Filament o Pellets? Introducing the Tumaker NX Pro Pellets

Currently 3D Printing is limited to those materials that exist in fi lament format. This is a handicap when it comes to the evolution and expansion of the use of 3D printers.

That is why we have decided to go to the origin. The pellet is the initial form of plastic. The format from which all fi laments are manufactured. Thanks to a new extrusion system developed by our engineers, we can print directly with the Pellets. In this way we fully open the range of printing possibilities. Thanks to this exclusive technology, we are able to reach new sectors and get new 3D printing applications. With our 3D pellet printing we can break the barriers making it possible to print with new materials or with certified and approved materials.

Impresora-3d-NX-Pro-pellet-PelletIzq

Now you can print with the approved
and certified materials for your sector

Only with 3D printing with pellets can you work with all those materials that do not exist in the form of a filament.

Many times the amount of material we need is minimal. For this reason many materials that are used in the industry in a small quantity are not filamented by the high cost that it would entail. However, thanks to the 3D printer with Pellet, we can manufacture with lightweight materials. Materials that are normally the only ones approved for certain sectors of activity.

Increased productivity by avoiding
tedious and expensive coil changes

The 3D pellet printers are the maximum exponent of the automation of the printing process. In the market there are coils of different sizes (up to 8 Kg), but no matter how large the coil is, we always have to make a technical stop for its change.

With Pellet 3D printing, we forget this process. The pellet feeds our 3D printer continuously and automatically. A device truly integrated into our production

process. The pellet is fed continuously and automatically to our 3D printer.

The only truly multi material 3D printer on the market

Forget about analyzing the fi laments on the market to discover which one is the closest to your usual materials. With the Pellets 3D printer, you can use your own material.

Thanks to it, you can print with the pellets that you use in your production injection processes. If you belong to a sector that requires certified and approved materials, this is your 3D printer. The only one with which you can work with certified material for your company. Prints with approved materials for the food industry, railway, automotive, medical sector, security, among others. Research, create and develop new materials that you can use for direct 3D printing on the 3D pellets printers.

Characteristics

Dimensions
Printing Volume: 290x180x200 mm
Printer Size: 550x440x460 mm
Package Size: 605x501x500 mm
Package Weight: 33 kg
Printer Weight 31 kg

Nozzle
Nozzle Diameter: 0.4 – 0.6 – 0.8 – 2.0 – 4.0 – 5.0mm
Nozzle temperature: 180ºC – 350ºC
Two temperature control points

Print
Materials in pellet format: PLA, ABS, PETG, FLEX A93, WOOD, ABS + CF, PC, PA12 + FERRITE, PA12 + NEODYMIUM, Polypropylene (PP), PP + Mineral Filler, HDPE, PC 766M, PC + CF, PVC, TPU A52, TPU <A50, PA66, Catamold, Ultem, Peek, Grilon BK-30, VALOX Resin 357X, PPC 7712.

Warm bed
Heated bed: 45º – 120º
Build Plate Leveling:

  • Manual
  • Semi-Automatic

Energy
Energy Smart Management
Power Rating: 950W
Noise Level: 44 dB
(closed door, 40dB)

Compatibility
Display: 5” color touch screen
Control devices: PC, tablet, Smartphone.
Control mode: Web

Resolution
Layer resolution: 10μm
Maximum Layer Height:

  • 5,0 nozzle: 4,1mm
  • 4,0 nozzle: 3,3mm
  • 2,0 nozzle: 1,6mm
  • 0,8 nozzle:0,6mm
  • 0,6 nozzle: 0,48mm
  • 0,4 nozzle: 0,3mm

Connectivity
USB, Wifi, SD Card
Ethernet (optional)

Software
Simplify3D Professional Software

warranty
1 Year Limited Warranty
